Hongli Electric Wall Chaser for Max 40 mm Grooving Depth and Width

Product Categories
Hangzhou Hongli Pipe Machinery Co., Ltd.
Contact Now

Hongli Electric Wall Chaser for Max 40 mm Grooving Depth and Width

Brand Name : Hongli

Model Number : HL1002

Certification : CE

Place of Origin : Zhejiang , China

MOQ : 50 sets after sample order

Payment Terms : T/T, L/C, Western Union

Supply Ability : 50000 sets per month

Delivery Time : 7-30 days as per your order

Packaging Details : Inner package BMC and outer package carton, packing size: 58*39*21 cm ,packing weight : 14 kg

Motor : 3500 W universal type

No load speed : 8500 RPM

Blades : Standard with 8 pcs of diamond blades

Contact Now

Hongli User-friendly Powerful Electric Wall Chaser for Max 40 mm Grooving Depth and Width

Features

1. Cutting tool: diamond disk.

2. The 1002 wall chaser features for an infrared light for precise working.

3. Suitable for air brick, red brick and cement-covered walls, focus-on reinforced concrete walls.

4. The cutting part is located at the head of the machine which will enable 1002 to cut slots even at the corner of the wall.

Specifications

Motor: Universal 3500 W, 220-240 V(AC) /50 Hz

No-load speed: 8500 RPM

Grooving width: 2.5-40 mm (there are totally 8 pcs of blades, if worked with 1 pc of blade, it is 2.5 mm, if 8 pcs, it could be 40 mm)

Grooving depth: 20-40 mm(you can adjust the depth by yourself)

Diamond Disk Size: 115 mm*22(in diameter)*2mm

Packing model: BMC

1002 wall chaser is standard with water cooling part.

Hongli Electric Wall Chaser for Max 40 mm Grooving Depth and Width

Spare diamond disk

Ordering Information

Catalog No. Model No. Description N.W(kg)
HL1002 Wall chaser, 220 V/50 Hz 9
diamond disk(8 pcs) 0.95


Hongli Electric Wall Chaser for Max 40 mm Grooving Depth and Width

Hongli Electric Wall Chaser for Max 40 mm Grooving Depth and Width
